1d Wireless Barcode Scanner With Memory, Best Wireless Barcode Scanner For Warehouse
Product Description:
This K-211R is one cheap and high cost effective 2.4g wireless laser barcode scanner.Plug and play with the USB receiver or the USB cable, no driver installation needed. Easy and quick to set up. Wireless transmission distance reaches up to 328 ft. in barrier free environment. Supports almost all 1D Barcodes: Codabar, Code 11, Code93, MSI, Code 128, EAN-128, Code 39, EAN-8, EAN-13, UPC-A, ISBN, Industrial 25, Interleaved 25, Standard 25, Matrix. Reads damaged, fuzzy, reflective and smudged barcodes.
Product Features:
• Installs quickly and easily
• Auto Data Detection
• Original wide-angle adjustable stand allows a broader scanning range
• Support all common 1d barcodes and popular interface
Product Specification:
| Performance Parameters |
| Light Sources | 617nm laser (Safe visible laser diode) |
| Supported Symbologies | UPC- A, UPC-E, EAN-13, EAN-8, Codabar, Code 39, Code 39 Full ASCII, China Post, Plessey, MSI, Code 93, Code 128, Industrial 2 of 5, Interleave 2 of 5, Matrix 2 of 5, Code 11, ISBN, ISSN, Code 32(Italian pharm code), Code 39 extended, ITF-14, RSS 14, etc. |
| Scan Type | Single Laser |
| Scan Speed | ≥150 times/s |
| Scan Method | Manual/Continuous/Automatic Scanning |
| Scan Angle | Yaw 55°, Rotation 30°, Pitch 65° |
| Precision | 4mil (0.1mm) |
| Depth of scan field | 10-250mm (0.33mm, PCS90%) |
| Error Rate | Less than 1/5million |
| Interface | USB-HID |
| Operating Frequency | 2.4G |
| Transmission Distance | 50-80M (Open Yard) |
| Storage Ability | 512000 Bytes |
| Pairing Model | One to one |
| Physical Parameters |
| Dimensions | 83mm*70mm*172mm |
| Weight | 152.2g |
| Material | ABS+PC, flameresistant material |
| Cable Length | 1.2m |
| Environmental Parameters |
| Operating Temperature | -20℃ ~ 40℃ |
| Storage Temperature | -40℃ ~ 70℃ |
| Relative Humidity | 0%~85% RH (Non-condensing) |
| Drop/Shock Resistance | Withstands multiple times 1.5 meters drops to concrete |
| Electrical Parameters |
| Voltage | DC5V±10% |
| Current | 85mA (Operating); 150uA (Standy Current) |
| Lithium battery | 550mA |
Product Pictures:
Product Application:
• Warehouse inventory management
• Transport and logistic
• Tracking
• Retail
• Point of sale
FAQ:
1. What information is in a 1D barcode?
In summary, 1D barcodes usually encode a string of numeric such as product number, production date, type, size, and so on. If you want to add text information into the 1D barcodes, Code 39, Code 93 and Code 128 help a lot. QR code and other 2D barcodes store large amounts of data, which allows for more flexible usage.
2. Can a barcode scanner read all barcodes?
Not all barcode scanners can read all barcodes. Laser barcode scanners and linear imagers read only 1D barcode scanners. Imager (camera-based) 2D barcode scanners read all common 1D and 2D barcodes.
3. What is difference between UPC and EAN?
A UPC is a 12-digit barcode used in North America to identify most products. The rest of the world uses 13-digit EAN barcodes to identify products. However, both types of barcodes are part of GS1's international standards, so both are accepted globally.
